30W CO2 Laser Therapy Apparatus Laser Beauty Device

Model Number JZ-1D
Minimum Order Quantity 1
Price Negotiation
Packaging Details export packing
Delivery Time 5-8WORK DAY
Payment Terms T/T
Supply Ability 20 Set/Sets per Month
Product Details
High Light

pirani vacuum sensor


thermocouple vacuum sensor


30W CO2 Laser Therapy Apparatus

Leave a Message
Product Description

The JZ-1D computer super-pulse CO2 laser treatment apparatus is an intelligent medical
equipments for surgery. It has an auto-test system of laser power, and the
unit adopt super engineering plastic (ABS) for the cabinet of machine with beauty,
credibility and security.
The unit can perform tens of laser operations such as accurate stripping, cutting
and vaporization of the soft tissues, the process being rapid with little damage
to surrounding tissues, little bloodshed and wounds healing faster and better.
The smoke-blowing system insid makes operations more clear, switch power with advanced
technique steadies the output power, special power control mode manages
to their depth and renge accurately, light conducting system guides the laser to
any small part, high reliable protecting system (water shut, over current shut,
over-voltage shut) and consummate design such as door locker, urgent stop, guarantee
the safe, reliable and long-life operation of the machine, Functions of the
unit is on the same level with that of the just type on abroad and its various
technical standard data has reached the advanced level at home.
JZ-1D has working mode with pulses of high repetition frequency, the power of which
can be compressed in time domain to high top power and instantaneous high temperature,
so it has apparent superiority on the cutting and vaporization of osteal pathological
changes. In situation where the continuous energy is needed, operating pulse
laser in higher repetition status, both the instantaneous high temperature could
gotten and the continuous high temperature could be kept, so the treatment for
osteal and soft tissue pathological changes could be more effective.
When used to treat the same disease, the pulse laser has much lower using power,
less damage to surrounding tissues, less pollution to environment and shorter heal
time than the continuous laser. All these are effect that traditional CO2 laser
therapy instruments can't achieve.
Specifications:Laser Type: CO2 Laser Device;Wavelength: 10.6μm;Mode: Low mode;Output Power: 1-30W, Adjustable;Starting Voltage: ≤25kV;Operating Voltage: ≤10kV;Operating Current: 3-25mA;Focal Flare Diameter: ≤0.4mm;Focal Length of Lens: f=100mm;Power Instability: <±10%;Indication Beam: 2mW 650nm red semiconductor laser;System control: microcomputer control, soft edition V2.0;Transmission System : 6-Joint Spring-Balanced Light Guiding Arm (with six kinds
of working heads);
Display: LCD.( Power and Pulse Output Time; Pulse Interrupted Time);Operating Mode:Continuous: 1-30W, step adjustable per 1W;Single pulse: opened time be accurately displayed and previewed, 0.01-2.95 seconds,
step adjustable per 0.01s;
Repeated pulse: opened and closed time be accurately displayed and previewed, 0.01-2.95
seconds, step adjustable per 0.01s;
Super pulse: modulated frequency of 1000Hz;Smoke emission: smoke-blowing system inside;Cooling System: built-in circulating water cooling;Input Voltage: AC110/220V; 50/60Hz;Environmental temperature: 5-40°C;Relative Humidity: ≤80%;Dimension: 400mm*370mm*1080mm;Weight: 21Kg.
